Ubiquiti UniFi Cloud Gateway Max UCG-Max

Podrobný popis

Compact 2.5G Cloud Gateway with 30+ UniFi device / 300+ client support, 1.5 Gbps IPS routing, and selectable NVR storage.

Includes full UniFi application suite for device management


Manages 30+ UniFi devices and 300+ clients


1.5 Gbps routing with IDS/IPS


Multi-WAN load balancing


512 GB NVMe SSD storage for NVR


0.96" LCM status display


USB-C powered (adapter included)

Technical Specifications
Mechanical
Dimensions 141.8 x 127.6 x 30 mm (5.6 x 5 x 1.2")
Weight 519 g (1.1 lb)
Enclosure material Polycarbonate

Hardware
Processor Quad-core ARM® Cortex®-A53 at 1.5 GHz
System memory 4 GB DDR4
On-board storage 512 GB NVMe SSD
Management interface Ethernet
Bluetooth
Networking interface LAN:
(4) 1/2.5 GbE RJ45 ports

WAN:
(1) 1/2.5 GbE RJ45 port
IDS/IPS throughput 1.5 Gbps*
*Measured with iPerf3 on a DHCP network. Performance may be reduced with PPPoE depending on ISP implementation.
Power method USB type C (5V DC/5A)
Supported voltage range 100–240V AC
Max. power consumption 16.1W
LCM display 0.96" status display
Button Factory reset
Ambient operating temperature -10 to 40° C (14 to 104° F)
Ambient operating humidity 5 to 95% noncondensing
Certifications CE, FCC, IC

Gateway Features
Performance Redundant WAN with failover and load balancing
WiFi QoS with UniFi APs
Application, domain, and country-based QoS
Application and device type identification
Additional internet failover with LTE Backup
Internet quality and outage reporting
Next-generation security Application-aware firewall rules
Signature-based IPS/IDS threat detection
Content, country, domain, and ad filtering
VLAN/subnet-based traffic segmentation
Full stateful firewall
Advanced networking License-free SD-WAN
WireGuard, L2TP and OpenVPN server
OpenVPN client
OpenVPN and IPsec site-to-site VPN
One-click Teleport and Identity VPN
Policy-based WAN and VPN routing
DHCP relay
Customizable DHCP server
IGMP proxy
IPv6 ISP support

LEDs
Ethernet Green: link/activity

Application Requirements
Mobile app UniFi iOS™ and Android™: Version 10.17.2 and later
